Slide Image Reveal
I recently saw a pretty nice image slider, showing before and after layered on top of each other, and being
able to move a slider to show more of the before or more of the after. So I decided I would like to recreate
it. It took just about two hours to throw this together, but most of that I would say was finessing rather
than writing the bones of the component.
Previously I had built a responsive image component,
where you give the image, and a range of fractions for how much of the page the image was to take up per
media size (or a single fraction if it didn't change on different page sizes), and pug/webpack would create
responsive images. This also includes webP images. I've integrated this set up
in other components, as I have here also. So both of these images are responsive to the sizing of the page,
as well as having webP options.
The live demo
<figure style="aspect-ratio: 3/4">
<picture class="slide-image-reveal__bottom">
<source srcset="..." sizes="..." type="image/webp">
<img src="..." alt="Right most image" srcset="..." sizes="..." height="1275" width="425" max-width="100%">
</picture>
<picture class="slide-image-reveal__top" id="top" ">
<source srcset="..." sizes="..." type="image/webp">
<img src="..." sizes="..." height="1275" width="425" max-width="100%">
</picture>
<span class="slider" id="slider""></span>
</figure>const initialise = () => {
const width = wrapper.clientWidth;
topPicture.style.width = "50%";
slider.style.transform = `translateX(${width / 2}px)`;
};
const affectImage = (clientX: MouseEvent["clientX"] | Touch["clientX"]) => {
const width = figure.clientWidth;
const offsetDiff = clientX - figure.offsetLeft;
topPicture.style.width = ((offsetDiff / width) * 100).toString() + "%";
slider.style.transform = `translateX(${offsetDiff}px)`;
};
